Siemens 6ES7137-6AA00-0BA0

The Siemens 6ES7137-6AA00-0BA0 is a fail-safe digital output module from the SIMATIC ET 200SP series. It provides 1 channel at 24V DC / 2A and is designed for safety-related applications according to SIL 3 and PL e standards. This module is ideal for use in distributed I/O systems where functional safety is critical.

◆ Key Features:

• Output Channels: 1 fail-safe digital output

• Output Voltage: 24V DC

• Max Output Current: 2 A

• Safety Level: SIL 3 (IEC 62061), PL e (ISO 13849-1)

• Width: 15 mm (compact design)

• Mounting: DIN rail (via BaseUnit)

• Module Type: F-DO (Fail-safe digital output)

• Protection Class: IP20

• Diagnostics: Integrated channel diagnostics and status LEDs

◆ Technical Specifications:

• Part Number: 6ES7137-6AA00-0BA0

• Series: SIMATIC ET 200SP

• Voltage Range: 19.2–28.8 V DC

• Connection Type: Requires BaseUnit (e.g., BU20 or BU15)

• Switching Type: High-side switching

• Short-Circuit Protection: Yes

• Operating Temp Range: –30°C to +60°C

• Dimensions (W x H x D): Approx. 15 x 73 x 58 mm

• Weight: Approx. 60 g

• Certifications: CE, UL, cULus, SIL3, PL e, RoHS

◆ Applications:

• Safety-critical machinery

• Emergency stop circuits

• Safety interlock systems

• Factory automation with fail-safe requirements

• Distributed I/O architectures using ET 200SP

◆ Why Choose the 6ES7137-6AA00-0BA0?:

• Fail-Safe Design: Meets stringent safety standards

• Space-Efficient: 15 mm wide for dense panel layouts

• Reliable Output: 24V DC, 2A with diagnostics

• Integrated Safety: SIL 3 and PL e certified

• Modular System: Seamless integration with ET 200SP infrastructure

NEW product in original sealed packaging. The product may be of older version or design. The packaging may have markings, signs of discoloration, and wear. FLATECK Warranty: 1 Year. Manufacturer's Warranty and Support NEVER apply
